Size: 12 in.
Inlet: 1/2 in. PEX
Hydrant meets ASSE 1019 code approval
Satin Nickel plated for long life
Large Cast Brass flange that is pitched to drain
Solid Brass body, Valve Stem Cap, Seat and Stem Ends
P-003 Vacuum Breaker meets ASSE 1011 code approval
Enclosed screw holes and self-aligning lug for easy installation
Stainless steel seat washer screw and handle screw
Powder coated metal handle
LEAD FREE"
Features
Body and seat composed of solid lead free brass (Pb ≤ 0.25%) for wetted surface area
Anti-siphon aluminum vacuum breaker with EPDM backflow preventer and backflow check valve
Wide and enclosed screw holes easily secure mounting screws
Integral cast flange with built-in drainage pitch
Solid brass body, valve stem cap, seat and stem ends
Satin nickel plated body maintains attractive finish
Stainless steel screws
Powder coated cast aluminum handle
AFG teflon with graphite packing for easy maintenance
Standard “OO” size seat washer
Each valve air-tested at factory for leak-free quality
Spout aligning mark with manufactuer’s date code
