200 Degree Gas Spillage Sensing Switch Kit with Manual Reset, 24VAC
$96.22
In stock
SKU
1629
1 Pole Thermal Safety Switch 24 VA
Description
Details
Field Controls Thermal Safety Switch, Series: SWG, 24 mVAC, 24 VA, 1 Pole, SPST
Our thermal safety switches efficiently detect flue gas spillage due to a blocked flue, continuous down drafting or inadequate draft condition. with the safety switch wired inch series with the burner circuit, the switch will de-energize the systems burner or burner control once it senses the spillage of hot flue gases. Available for gas-fired and oil-fired applications.
Features
Features
Number of Poles: 1
Amperage Rating: 24 VA
Contact Form: SPST
Thermal safety switch detects the increased heat generated by the flue gas spillage and deactivates the furnace or boiler
It will not allow the burner to restart until the switch has been manually reset
Gold contact material
Normally closed switch: opens at 200 deg F and manual reset close
Thermal safety switch are used when on barometric draft controls and draft hoods to detect flue gas spillage and deactivate oil and gas burners
Kit same as SSK-2 Kit, except switches not enclosed in electrical box
