Intermittent Universal Pilot Ignition Module, 24 VAC
$166.96
In stock
SKU
1855889
Intermittent Universal Pilot Ignition Module 24 VAC
Description
Details
Honeywell Universal Pilot Ignition Module, Intermittent, 24 VAC, 3-15/16 inch height x 5-7/16 inch Width x 2-5/8 inch D
Universal intermittent pilot ignition module replaces multiple field installed intermittent pilot modules supplied by Honeywell, Robertshaw, Johnson and UTEC (HSC). Uses existing intermittent pilot burner. Includes cross reference, instructions and accessories for easy replacement.
Features
Features
Warranty: Limited
Height: 3-15/16 in
Width: 5-7/16 in W
Depth: 2-5/8 in
Domestic/Import: Import
Includes: Damper Plug
Specifications: 24 VAC
Replaces over 400 White-Rodgers, Robertshaw® and Honeywell® intermittent pilot ignition modules
Provides ignition sequencing, flame monitoring and safety shutoff for intermittent pilot warm air furnaces and heating appliances
Provides 100 percent pilot gas shutoff if pilot fails to light; after 6 min delay, trial for ignition is repeated
Ignition trail/delay sequence is repeated until the appliance lights or call for heat is removed
For use with natural or LP gas
For use in single rod or dual rod or remote sense applications
Includes spark cable adapters to allow field replacement of both Honeywell® and competitive controls without replacing existing spark cable
